XC7WH14
图像仅供参考
请参阅产品规格
XC7WH14
-
商品编号:
XC7WH14GT,115
-
简述:
Triple inverting Schmitt trigger
-
描述:
The XC7WH14 is a high-speed Si-gate CMOS device. This device provides three inverting buffers with Schmitt trigger action. This device is capable of transforming slowly changing input signals into sharply defined, jitter-free output signals.
- 数据手册:
库存: 0
特性
Symmetrical output impedance
High noise immunity
ESD protection:
HBM JESD22-A114F exceeds 2000 V
MM JESD22-A115-A exceeds 200 V
CDM JESD22-C101D exceeds 1000 V
Low power dissipation
Balanced propagation delays
Multiple package options
Specified from -40 ℃ to +85 ℃ and -40 ℃ to +125 ℃
目标应用
Wave and pulse shaper for highly noisy environment
Astable multivibrator
Monostable multivibrator
