图像仅供参考
请参阅产品规格
-
商品编号:
PSMN072-100MSEX
-
简述:
100MSE - N-channel 100 V, 77 mOhm standard level ASFET with enhanced SOA in DFN2020. Designed for high power PoE, inrush management, eFuse and relay replacement
-
描述:
New standards and proprietary approaches are enabling Power-over-Ethernet (PoE) systems capable of delivering up to 90 W to each powered device (PD). Such solutions place increased demands on the power sourcing equipment (PSE) in terms of “soft-start”, thermal management and power density requirements. These ASFETs combine enhanced SOA in a compact 3.3 mm x 3.3 mm footprint making them ideally placed for a variety of applications including HP-PoE, eFuse and relay replacement.
- 数据手册:
特性
Enhanced safe operating area (SOA) for superior linear mode operation
Low RDSon for low I2R losses
Ultra reliable LFPAK33 package for superior thermal and ruggedness performance
Very low IDSS leakage
目标应用
PoE applications
IEEE802.3at and proprietary PoE solutions
Fault tolerant load switch - inrush management and eFuse applications
Battery management applications
Relay replacement
WIFI hotspots
5G picocells
CCTV
