PMPB29XNEA

main product photo

图像仅供参考

请参阅产品规格

PMPB29XNEA

商品编号:
PMPB29XNEAX
简述:
30 V, N-channel Trench MOSFET
描述:
N-channel enhancement mode Field-Effect Transistor (FET) in a leadless medium power DFN2020MD-6 (SOT1220) Surface-Mounted Device (SMD) plastic package using Trench MOSFET technology.
数据手册:
下载数据手册

跳转到图像库的开头

库存: 99981999

数量:

单价: ¥0.8511

总价: ¥0.8511

价格（包含13%的增值税）

数量单价总价: 1 ¥0.8511 ¥0.8511; 500 ¥0.7738 ¥386.9000; 1000 ¥0.7369 ¥736.9000; 3000 ¥0.7018 ¥2,105.4000

特性

Low threshold voltage
Trench MOSFET technology
Side wettable flanks for optical solder inspection
ElectroStatic Discharge (ESD) protection > 500 V HBM (class H1B)
AEC-Q101 qualified

目标应用

Relay driver
High-speed line driver
Low-side load switch
Switching circuits
