PMEG6010CPAS
图像仅供参考
请参阅产品规格
PMEG6010CPAS
-
商品编号:
PMEG6010CPASX
-
简述:
60 V, 1 A low VF dual Schottky barrier rectifier
- 描述:
- 数据手册:
库存: 0
特性
Average forward current IF(AV) ≤ 1 A
Reverse voltage VR ≤ 60 V
Low forward voltage VF ≤ 540 mV
Low reverse current
Reduced Printed-Circuit-Board (PCB) area requirements
Exposed heat sink (cathode pad) for excellent thermal and electrical conductivity
Leadless small SMD plastic package with visible and solderable side pads
Suitable for Automatic Optical Inspection (AOI) of solder joints
AEC-Q101 qualified
目标应用
Low voltage rectification
High efficiency DC-to-DC conversion
Switch Mode Power Supply (SMPS)
Free-wheeling application
Reverse polarity protection
Low power consumption application
Battery chargers for mobile equipment
LED backlight for mobile application
数据手册
